use:Used in aluminum oxide powder medium temperature calcination
The main technical parameters
1. Furnace length: 36 ~ 48m
2. Feed mode: 4 ~ 6 crucible single-layer (double layer) parallel into kiln
3. Power: 800 ~ 900KW / 380V (adjustable)
4. Using the highest use: 1250 ° C
5. Common Process Temperature: 800-1150 ° C
6. Steady energy consumption: 300-500A / 380V / h
7. Heating temperature zone: 18 ~ 25, 36 ~ 50 points, control temperature up and down
8. Heating components: electric hot alloy wire + silicon carbon rod
9. Sealing: front and rear double gate
10. Control mode: SCR control, smart meter PID continuous adjustment, PLC + touch screen automatic monitoring
11. Transfer method: variable frequency motor + reducer + slope gear + roller stick
12. Inner atmosphere: air
13. Supporting equipment: external circulatory mechanism
Please contact us with details.
